Configure and print custom barcode and labels
Configure barcode labels of your choice like Material Label with custom fields in the label.
Create Barcode Labels using Existing Barcode Labels
Scan and capture data barcode labels to generate new labels for any configurable fields. When a barcode label is scanned, the data in the fields is captured and populated on the app. Use the data to generate another barcode label. You can create this option the Searches menu.

Title and Copyright
Copyright and Terms of Use for RACE™ Configurations Guide for mInventory, a Mobile Inventory Management Solution of Connected Workforce Platform^TM.
Preface
Understand audience, know related documents and products and conventions followed in this document.
Understand RACE™
Innovapptive’s Connected Workforce Platform™ uses built-in integrations to connect your SAP®, IBM Maximo, and other back-office systems with mobile applications.
Upload mInventory preset Configuration Spreadsheets Using RACE™
RACE™ configurations are provided in spreadsheets. Upload the spreadsheets in RACE™ to enable the latest mInventory features.
Enable/disable modules and features
When you upload RACE preset configuration spreadsheets, all the standard features and configurations that are required for the mobile application are enabled. You can disable the features that are not required for your organization or not applicable for your industry.
Define Defaults, Filters and Search Criteria
Defaults, Filters and Dynamic Search configuration settings through RACE™.
Create custom screen for an existing module
Innovapptive provide you modules and screens out of the box to cater to your core business processes. However, you can also create additional screens on the fly using RACE™ to cater to your business requirements.
Configure Extensions
Extensions help you configure additional fields and properties, modify the properties of standard fields or create and map a new field from the SAP system.
Enable Scan functionality
You can convert search fields to scan fields. When you do this, you can capture data by scanning and post your transactions without the need to enter or update values manually. You can enable the following types of functionality using RACE™ for your mobile applications.
Optimize Performance and Define Offline Configuration Parameters
Use the Performance menu to define the performance optimization and offline configuration parameters for the application.
Configure Printers
You can configure the following printers using RACE™.
Configure Scanner/Peripheral devices
You can configure the scanners and peripheral devices that you use using RACE™.
Define localization entries
Use the Localization menu to define the local language translation for UI fields.
Configure attachments types
Learn to configure attachment types like PDF, DOC, TXT and JPG for mobile application and post them to Archive server (DMS, Archive Link).
Configure and print custom barcode and labels
Configure barcode labels of your choice like Material Label with custom fields in the label.
- Configure template for Barcode labels
  Learn to configure template for barcode labels with parameters like Barcode Type, Layout, Height and Width.
- Configure Print Label Layouts
  Configure print label layout using the Extensions menu.
- Print Labels
  Option to print labels are enabled by default in RACE. You can enable or disable them in the Extensions menu.
- Create Barcode Labels using Existing Barcode Labels
  Scan and capture data barcode labels to generate new labels for any configurable fields. When a barcode label is scanned, the data in the fields is captured and populated on the app. Use the data to generate another barcode label. You can create this option the Searches menu.
Create custom module and screens (Add New module)
Configure module and screens of your choice to cater to your specific business requirements

Create Barcode Labels using Existing Barcode Labels

Scan and capture data barcode labels to generate new labels for any configurable fields. When a barcode label is scanned, the data in the fields is captured and populated on the app. Use the data to generate another barcode label. You can create this option the Searches menu.

To configure barcode label,

Click the Searches option in the left navigation menu.
Click the Filter button next to the Searches field.
Select Label Printing for the Module field.

Figure 1. Barcode Label Preview Configuration Screen

Enter the following string in the Default Value field.

{
	"SEPERATOR": "~",
	"COMBOSCAN": [
		[{
			"FIELDNAME": "EBELN",
			"FIELDLENGTH": "10",
			"SEARCHTYPE": "H",
			"OPERATIONTYPE": "B",
			"MANDATORY": "",
			"CATEGORY": "STANDARD",
			"OPTIONAL": ""
		}, {
			"FIELDNAME": "EBELP",
			"FIELDLENGTH": "10",
			"SEARCHTYPE": "I",
			"OPERATIONTYPE": "B",
			"MANDATORY": "",
			"CATEGORY": "STANDARD"
		},{
			"FIELDNAME": "MATNR",
			"FIELDLENGTH": "10",
			"SEARCHTYPE": "I",
			"OPERATIONTYPE": "B",
			"MANDATORY": "",
			"CATEGORY": "STANDARD",
			"OPTIONAL": ""
		},{
			"FIELDNAME": "OPENQTY",
			"FIELDLENGTH": "10",
			"SEARCHTYPE": "I",
			"OPERATIONTYPE": "B",
			"MANDATORY": "",
			"CATEGORY": "STANDARD",
			"OPTIONAL": ""
		}]
	]
}

Click Save.
