Install mInventory
Ensure that the preinstallation requirements are met before you install mInventory. See Pre Install or Pre Upgrade Configurations Guide for information.
Install supporting systems

Title and Copyright
Copyright and Terms of Use for Install Guide for mInventory, a Mobile Inventory Management Solution of Connected Workforce Platform^TM .
Preface
Understand audience, know related documents and products and conventions followed in this document.
Install mInventory
Ensure that the preinstallation requirements are met before you install mInventory. See Pre Install or Pre Upgrade Configurations Guide for information.
- Install supporting systems
- Install mInventory
Install RACE™ SAP® ECC and Gateway
Add-On: All the transports of previous releases and the transports of the current release are packaged into a single add-on for the main release. For example, 2003, 2006 and so on. Install the add-on for the current release that is provided by Innovapptive representative.
Install mInventory SAP® ECC, Gateway, and UI5
Add-On: All the transports of previous releases and the transports of the current release are packaged into a single add-on for the main release. For example, 2003, 2006 and so on. Install the add-on for the current release that is provided by Innovapptive representative.
Check Schema Change Indicator
After importing support packs into the systems, perform the following steps to check the Schema Change Indicator.
SAP Gateway cache clean up
Clean up the SAP Gateway Cache after importing support packs into the systems.
Configure SAP Gateway for mInventory
SAP Material Management (MM) users can use mInventory to do the following:
Configure RACE™ for mInventory
Innovapptive’s Connected Workforce Platform™ uses built-in integrations to connect your SAP®, IBM Maximo, and other back-office systems with mobile applications. This helps organizations bridge communication and information gaps between executive teams, field technicians, plant operators, warehouse operators, maintenance engineers, and back-office staff. Connect data points across cloud and on-premise networks to quickly and easily.
SAP transactions and tables for mInventory
The following table provides the list of key SAP transactions and tables for mInventory.
Deploy MIM UI5 package to SAP Cloud platform (SCP)
Do the following to deploy MIM UI5 package to SCP:
Implement BADIs
mInventory uses SAP oDATA based on RESTful design. mInventory performs service calls to read and post data from the SAP Business backend system. These service calls invoke remote enabled function modules in the backend systems to either get or post data depending on the direction of the call. Like Standard SAP code, Innovapptive Add-On code objects cannot be modified in customer systems.
Generate Secondary Indices
To improve the application performance, for tables containing large amounts of data, generate secondary indices for key tables relevant for the product.
Update Resource File
This section describes the steps to view and modify the content, format, and structure of the Resources file.
Download App and Install
Download the latest version of mInventory app from Apple App Store, Google Play or the Microsoft Store and install it on your devices.

Install supporting systems

Install the following supporting systems as part of the preinstallation requirements.

Table 1. Prerequisites
System and Software	SAP ECC Business Suite backend with SAP_BASIS component (702 and above) and connected to the mobile infrastructure (NetWeaver gateway, SMP/SCPms). SAP NetWeaver Gateway 7.4 and above with SAP_BASIS component (740 and above), SAP_GWFND component (SP 10 and above) and SAP_UI component (SP 13 and above). SPAM/SAINT version with at least 69. SMP 3.0 SP 10 and above or SCP with Cloud Connector is already configured. SAP SCP Client Tenant. SAP Cloud Connector minimum 2.x and above (latest version is recommended).
Access	SAP Basis System Admin with access to 000 clients in Gateway and ECC systems. Access to SAP File directory usr/sap/trans/EPS/in to upload PAT files.
Assumptions	Access to the RACE™ portal can be completed after the RACE™ admin user credentials setup is completed.

Install the supporting systems in the order defined in the flow.

Figure 1. Install Systems
